Condor Pressure Switch MDR 5/16 2,5-16 bar G 1/2" Alu

Price:

186.95 €

English (US)
  2. Shop
  3. Condor MDR 5
  4. Condor Pressure Switch MDR 5/16 2,5-16 bar G 1/2" Alu
Condor Pressure Switch MDR 5 2,5 - 16 bar K 1/2" + 1/4"
Condor Pressure Switch MDR 5 2,5 - 16 bar K 1/2" + 1/4"
208.61 € 208.61 €
Condor Pressure Switch MDR 5/5-K 1,5-5 bar G 1/2“ Alu
Condor Pressure Switch MDR 5/5-K 1,5-5 bar G 1/2“ Alu
137.56 € 137.56 €

Condor Pressure Switch MDR 5/16 2,5-16 bar G 1/2" Alu

https://staging-filcom-16.laminfra.de/web/image/product.template/217574/image_1920?unique=d4441e6

186.95 € 186.95000000000002 EUR 186.95 € VAT Included

157.10 € VAT Included


Price tiers visible after login - register now and get your benefits!
  • Brand

This combination does not exist.


Price Tiers

Contact Us
Condor-Werke

Condor-Werke

The Condor Group is a global leader in manufacturing components and system solutions for the control and regulation of pressure and level. With their extensive range, they cater to various industries and applications such as industrial automation and water and wastewater technology

Product no. :

212973

Category :

Condor MDR 5

Weight :

0.82 kg

Condor pressure switch MDR 5/16 bar 212973

Three-phase version
Switching capacity 5.5
Pressure range 2.5 - 16.00 bar
3-pole (NC contact)
In accordance with EN 60947
The manufacturer reserves the right to make technical changes!

Pressure switch type: HAA BAAA 130A160 XXX XXX see further information under Documents.
Required relief valves, cable glands, covers for retrofitting see under "Accessories".

Thread / connection G 1/2" aluminum
Protection class IP 54
Motor switching capacity (kW) 5.5 kW
Max. media temperature (°C) 80°C
Current version Three-phase current
Type of construction Electro-mechanical
Tension ≤ 400 V
Contact function 3-pole (normally closed contact)
Rated frequency 50 Hz / 60 Hz
Weight (in g) 820
Pressure range (bar) 2.5 - 16
Model range - Pressure switch MDR 5
On / Off switch button No
Condor Betriebsanleitung MDR 5
Download
Condor Datenblatt MDR 5
Download

Similar Products

Product Price
[212997] Condor Pressure Switch MDR 5/16 2,5-16 bar G 1/2" + G 1/4" Alu 169.20 €

Accessory Products

Product Price
[201878] Condor Unloader valve EV 5 with screw connection for 6 mm plastic or copper discharge tube, screw connection for vent port 36.50 €
[201885] Condor Unloader valve EV 5i with screw connection for 1/4" plastic or copper discharge tube 36.50 €
[201892] Condor Unloader valve EV 5E with screw connection for 6 mm plastic or copper discharge tube 27.30 €
[201908] Condor Unloader valve EV 5Ei with screw connection for 1/4" plastic or copper discharge tube 27.30 €
[201915] Condor Unloader valve EV 5H with screw connection for 6 mm plastic or copper discharge tube, screw connection for vent port (for MDR-5/45 bar types) 35.60 €
[202028] Condor Thermal, 3-pole overload relay R5 0,86 - 1,50 A 69.40 €
[202035] Condor Thermal, 3-pole overload relay R5 1,50 - 2,45 A 69.40 €
[202042] Condor Thermal, 3-pole overload relay R5 2,40 - 4,20 A 69.40 €
[202059] Condor Thermal, 3-pole overload relay R5 4,00 - 7,00 A 69.40 €
[202066] Condor Thermal, 3-pole overload relay R5 6,10 - 10,3 A 72.20 €
[202073] Condor Thermal, 3-pole overload relay R5 9,00 - 14,0 A 90.50 €
[202080] Condor Thermal, 3-pole overload relay R5 11,0 - 18,0 A 90.50 €
[230045] Condor Mounting bracket 12.40 €
[269496] Condor Grommet WN M20 for cable gland MDR 5 4.60 €
[269502] Condor Screw plug M20 2.50 €
[269519] Condor Cable gland M20 L with strain relief, clamping range 10-14 mm 11.00 €
[269526] Condor Cable gland M20 LK with strain relief and cable support, clamping range 10-14 mm 11.20 €
[269533] Condor Cable gland M20 Z with strain relief, clamping range 6-12 mm 11.00 €
[269540] Condor Cable gland M20 ZK with strain relief and cable support, clamping range 6-12 mm 11.20 €
