Wortmann Oil-water-seperators model drukomat 31plus
For over 35 years, Wortmann has been providing practical system solutions for compressed air treatment
Wortmann Drukomat 31plus oil water separator 3231, incl. a filter set.
The Drukomat 31plus reliably de-oils the condensate produced through a combination of deflection and calming chamber, as well as a series connection of coalescence and activated carbon filter directly at the point of origin.
The treated condensate can be discharged directly into the sewer system as purified water.
New with Preko flow filter
- self-cleaning
-better efficiency
-greater performance with extended filter service life
The Preko flow filter ensures that the finely dispersed oil droplets in the condensate adhere to any oil present and are forced to float due to the direction of flow in the Preko filter.
The Preko flow filter has proven to be highly efficient and is even self-cleaning due to its design and the direction of flow of the condensate.
Filtration:
1 x prefilter
1 x prefilter
2 x activated charcoal filter
1 x exhaust air side
The Drukomat has a building authority approval Z-54.8-85 from the German Institute for Building Technology and does not require a water law permit.
For further technical data, see "Downloads" below.
| Max. Compressor capacity (m³/min) | 40 |
| Height (mm) | 1.160 |
| Width (mm) | 850 |
| Depth (mm) | 520 |
| Condensate inlet connection | 4x 1/2" |
| Water drain connection | 1" |
| Oil drain connection | 1" |
| Filtering exhaust air (l) | 1088 |
| Water filtration (litres) | W31 plus |
