TR screw-in connection, 16.5 x 1/2"
Transair®, a division of Parker, specializes in the development and manufacturing of compressed air supply solutions tailored to the demanding needs of industrial applications
Transair Legris screw-in connection Ø16.5 × 1/2" BSP conical - 66051721
Connects Transair Ø 16.5 pipes with existing 1/2" threaded connections on compressors, dryers and machines.
Technical data
- Connection: Transair Ø16.5 to 1/2" BSP conical
- Max. Operating pressure: 16 bar (-20°C to +45°C), 13 bar (-20°C to +60°C)
- Seal: NBR - leak-proof without additional sealing material
- Suitable media: Compressed air, vacuum, nitrogen, inert gases
Application areas
Wherever Transair lines are connected to existing threaded installations: Compressors, dryers, filters, pressure reducers, machines and existing lines made of steel pipe. Also for breathing air distribution systems and inert gas applications in the chemical and pharmaceutical industries.
