Filtration Group filter element PI 22010 RN PS 6
Filtration Group's filtration and separation solutions ensure success, guarantee trouble-free plant operation, promote clean working environments and protect valuable capital goods
Filtration Group (formerly MAHLE) Return filter element Pi 22010 RN PS6 / 77940844
Longer service life than conventional filters
Lower energy consumption due to lower differential pressure for longer
Up to 30% more dirt-holding capacity compared to standard products
Guaranteed defined filter retention rate according to ISO 16889 (multi-pass test) over the entire operating time
Star-pleated filter element
Corrosion-protected end caps and support tubes, chrome VI free
Flow direction from outside to inside
Temperature application range -10 °C to +120 °C
For DIN elements: Standard seals NBR, other seals on request
| Filter element | Standard element |
| Seal material | NBR |
| Nominal size (l/min) | 100 |
| Height (mm) | 248 |
| Outer diameter (mm) | 58 |
| Inner diameter (mm) | 32.2 |
| Mounting diameter (mm) | 32.2 |
| Differential pressure resistance (bar) | 20 |
| Filter material | Glass fiber |
| Filter fineness (micrometres) | 6 |
| End disc material | Sheet metal end plate |
