Filtration Group filter element line filter Pi 71010 DN PS VST3
Filtration Group's filtration and separation solutions ensure success, guarantee trouble-free plant operation, promote clean working environments and protect valuable capital goods
Filtration Group (formerly MAHLE) Filter element Inline filter Pi 71010 DN PS VST3 / 78227480
Longer service life than conventional filters
Lower energy consumption due to lower differential pressure for longer
Up to 30% more dirt-holding capacity compared to standard products
Guaranteed defined filter retention rate according to ISO 16889 (multi-pass test) over the entire operating time
Star-pleated filter element
Corrosion-protected end caps and support tubes, chrome VI free
Flow direction from outside to inside
Temperature application range -10 °C to +120 °C
For DIN elements: Standard seals NBR, other seals on request
| Filter element | Standard element |
| Seal material | NBR |
| Nominal size (l/min) | 100 |
| Height (mm) | 247.7 |
| Outer diameter (mm) | 45 |
| Inner diameter (mm) | 22.1 |
| Mounting diameter (mm) | 22.1 |
| Differential pressure resistance (bar) | 210 |
| Filter material | Glass fiber (reinforced) |
| Filter fineness (micrometres) | 3 |
| Differential pressure (bar) | 210 |
| Element type | Standard element |
| Filter material | Glass fiber (reinforced) |
| Nominal height (mm) | 247,7 |
| Medium | Hydraulic oil |
| Nominal size | 100 |
