BEKO Active Oil-water separator QWIK-PURE 30 (with 3 meter power cable)

BEKO QWIK-PURE 30: Active condensate treatment with maximum flexibility

The BEKO oil-water separator model QWIK-PURE 30 with 3-meter power cable (item no. 4055900) redefines efficiency in larger compressed air stations. While conventional separators work purely passively, the QWIK-PURE 30 uses light blasts of compressed air to actively guide the condensate through the two filter cartridges. The integrated 3-meter power cable ensures uncomplicated commissioning and allows flexible installation in your station.

The system is the ideal choice for demanding industrial applications: With its capacity of 30 m³/min, it offers maximum safety for your compressed air treatment.

Your benefits with the active QWIK-PURE 30:

• Active mode of operation: The condensate is pressed through the filters in a controlled manner. This effectively suppresses the formation of impermeable boundary layers and bacterial cultures, even at high throughput rates.
• Hygienic & safe: The hermetically sealed cartridges protect personnel from contamination. Free oils are bound directly inside, making open oil containers a thing of the past.
• Dual cartridge system: The load is optimally distributed across two units, which maximizes service life and significantly increases process reliability.
• Flexible connection: The factory-fitted 3-meter power cable allows simple electrical connection without complex additional installations.
• Ergonomic handling: Despite being fully saturated, each cartridge weighs a maximum of 25 kg. The inlet tube serves as a sturdy handle for convenient replacement.
• Certified legal certainty: The DIBt approval confirms reliable compliance with the legal discharge values (max. 10 mg/l residual oil content).

Maintenance & service for QWIK-PURE 30:

• No pre-soaking: The standard cartridges are ready for immediate use - there is no need for time-consuming pre-soaking.
• Maintenance without downtime: Inflowing condensate is buffered in the large pressure relief chamber during the cartridge change.
• Clean change: The integrated bottom valve closes automatically when removed. The cartridges are securely sealed for removal with the blind plugs supplied.
• Sustainability: The filter material of both cartridges is fully utilized thanks to the active flow. This leads to longer service lives with an optimized environmental balance.
